Up to 100 MHz or 125MHz

Embedded Memory

Up to 512KB of Flash (ECC)
Up to 32KB of RAM (ECC or Parity)
Up to 64KB of Shared RAM
2KB of IPC Message RAM

Five Universal Asynchronous Receiver/Transmitters (UARTs)

Four Synchronous Serial Interfaces (SSIs) and a Serial Peripheral Interface (SPI)

Two Inter-integrated Circuits (I2Cs)

Universal Serial Bus On-the-Go (USB-OTG) + PHY

10/100 ENET 1588 MII

Two Controller Area Network,
Clocking

Interprocessor Communications (IPC)
32 Handshaking Channels
Four Channels Generate IPC Interrupts
Can be Used to Coordinate Transfer of Data Through IPC Message RAMs

Up to 74 Individually Programmable, Multiplexed General-Purpose Input/Output (GPIO) Pins

Up to 150 MHz

C28x Core Hardware Built-in Self-Test

Embedded Memory
Up to 512KB of Flash (ECC)
Up to 36KB of RAM (ECC or Parity)
Up to 64KB of Shared RAM
2KB of IPC Message RAM

IEEE-754 Single-Precision Floating-Point Unit (FPU)
Viterbi, Complex Math, CRC Unit (VCU)

Serial Communications Interface (SCI)/SPI/I2C

Nine Enhanced Pulse Width Modulator (ePWM) Modules 18 Outputs (16 High-Resolution)

Six 32-Bit Enhanced Capture (eCAP) Modules

Three 32-Bit Enhanced Quadrature Encoder Pulse (eQEP) Modules

Dual 12-Bit Analog-to-Digital Converters (ADCs)
Up to 2.88 MSPS
Up to 20 Channels
Four Sample-and-Hold (S/H) Circuits

Up to Six Comparators With 10-Bit Digital-to-Analog Converter (DAC)
