TMS320C28x 32-bit CPU

• 100 MHz

• IEEE 754 single-precision Floating-Point Unit (FPU)

• Trigonometric Math Unit (TMU)

  • 3×-cycle to 4×-cycle improvement for common trigonometric functions versus software libraries

  • 13-cycle Park transform

• Viterbi/Complex Math Unit (VCU-I)

• Ten hardware breakpoints (with ERAD)

Programmable Control Law Accelerator (CLA)

• 100 MHz

• IEEE 754 single-precision floating-point instructions

• Executes code independently of main CPU

On-chip memory

• 256KB (128KW) of flash (ECC-protected) across two independent banks

• 100KB (50KW) of RAM (ECC-protected or parity-protected)

• Dual-zone security supporting third-party development

• Unique Identification (UID) number

Clock and system control

• Two internal zero-pin 10-MHz oscillators

• On-chip crystal oscillator and external clock input

• Windowed watchdog timer module

• Missing clock detection circuitry

1.2-V core, 3.3-V I/O design

• Internal VREG or DC-DC for 1.2-V generation allows for single-supply designs

• Brownout reset (BOR) circuit

System peripherals

• 6-channel Direct Memory Access (DMA) controller

• 40 individually programmable multiplexed General-Purpose Input/Output (GPIO) pins

• 21 digital inputs on analog pins

• Enhanced Peripheral Interrupt Expansion (ePIE) module

• Multiple low-power mode (LPM) support with external wakeup

• Embedded Real-time Analysis and Diagnostic (ERAD)

Communications peripherals

• One Power-Management Bus (PMBus) interface

• One Inter-integrated Circuit (I2C) interface (pin-bootable)

• Two Controller Area Network (CAN) bus ports (pin-bootable)

• Two Serial Peripheral Interface (SPI) ports (pin-bootable)

• Two UART-Compatible Serial Communication Interfaces (SCIs) (pin-bootable)

• One UART-Compatible Local Interconnect Network (LIN)

• One Fast Serial Interface (FSI) with a transmitter and receiver

Analog system

• Three 3.45-MSPS, 12-bit Analog-to-Digital Converters (ADCs)

  • Up to 21 external channels

  • Four integrated post-processing blocks (PPBs) per ADC

• Seven windowed comparators (CMPSS) with 12-bit reference Digital-to-Analog Converters (DACs)

  • Digital glitch filters

• Two 12-bit buffered DAC outputs

• Seven Programmable Gain Amplifiers (PGAs)

  • Programmable gain settings: 3, 6, 12, 24

  • Programmable output filtering

Enhanced control peripherals

• 16 ePWM channels with high-resolution capability (150-ps resolution)

  • Integrated dead-band support with high resolution

  • Integrated hardware trip zones (TZs)

• Seven Enhanced Capture (eCAP) modules

  • High-resolution Capture (HRCAP) available on two modules

• Two Enhanced Quadrature Encoder Pulse (eQEP) modules with support for CW/CCW operation modes

• Four Sigma-Delta Filter Module (SDFM) input channels (two parallel filters per channel)

  • Standard SDFM data filtering

  • Comparator filter for fast action for overvalue or undervalue condition

Configurable Logic Block (CLB)

• Augments existing peripheral capability

• Supports position manager solutions

InstaSPIN-FOC™

• Sensorless field-oriented control (FOC) with FAST™ software encoder

• Library in on-chip ROM memory
