Digital
Power System (DPS)
數位電源控制相關設備與套件，包含DC/DC、AC/DC控制系統，使用一顆數位訊號處理晶片，處理器部分區分成C2000高效能32位元晶片與UCD3138系列晶片。
一、數位電源DSP整合式套件(採用德州儀器C2000控制處理器):
| 整合式套件 |
型號 |
說明 |
 |
C2000高效能32位元處理晶片說明 |
- 整合DSP數學運算的能力與控制周邊裝置，是一個極具高效能的微控制晶片與數位訊號處理器
|
 |
高壓Digital
Resonant LLC Converter開發平台(採用F28027處理晶片) |
- Quick Start Graphical User
Interface
- 380-400V DC input, 500 watt
12V regulated DC output
- Supports Synchronous
Rectification output control
- Four different feedback
methods for experimentation
- Lossless current sensing
circuit for fault protection
Open source hardware and software with full documentation
- Detailed lab and discussion
of Resonant LLC Principles
|
 |
高壓相位移位全橋DC/DC開發平台(採用F28027處理晶片) |
- Supports Peak Current Mode
Control with Slope Compensation
- Quick Start Graphical User
Interface
- 380-400V DC input, 500 watt
12V regulated DC output
- Multiple feedback methods
for experimentation
- Lossless current sensing
circuit for fault protection
- Open source hardware and
software with full documentation
- Detailed lab and discussion
of PSFB Principles.
|
 |
高壓2-Phase
Interleaved PFC開發平台(採用F28027處理晶片) |
- 300W 2-Phase Interleaved PFC
- Universal AC Line Input (85
to 265V)
- 390V Regulated DC Output
|
 |
高壓Bridgeless PFC 開發平台(採用F28035處理晶片) |
- Fast Feed Forward half cycle
RMS control loop
- RMS Input voltage and
frequency monitoring
- 300W Bridgeless 2-Phase
Interleaved PFC
- Universal AC Line Input (85
to 265V)
- 390V Regulated DC Output
- Detailed lab and discussion
of PFC Principles.
|
 |
高壓2-Phase
interleaved PFC開發平台(採用F28035處理晶片) |
- Full digital control of dual
interleaved PFC topology
Worldwide voltage input (95VAC to 265VAC)
- 400VDC Bus operating up to
700 Watts
- Low CPU loading
- High efficiency and PF with
low THD
- Input power metering for RMS
current, Voltage, power and frequency measurement
|
 |
數位電源與能源控制(Power)教學平台(採用F28035/F28069/F28335處理晶片) |
-
為電力電子工程師提供了一種探索和了解數位電源設計的開發發展平台
|
 |
C2000系列JTAG除錯模擬器與Flash燒錄器 |
|
 |
Code Composer Studio V6.x
New! |
-
最新版軟體開發環境，可支援全系列MSP430/ARM/DSP處理器，可安裝於WIN7/8/10
|
二、數位電源DSP整合式套件(採用德州儀器UCD3138整合式控制處理器):
| 整合式套件 |
型號 |
說明 |
 |
UCD3138處理器說明 |
- 晶片內建硬體功能PID演算的數位電源處理器
- Highly Integrated Digital Controller for
Isolated Power with 3 Feedback Loops and 8 DPWM Outputs
|
 |
UCD3138(40-pin)開放式系統 |
-
採用UCD3138(40-pin)數位處理器的開放式系統，包含基本周邊、腳位控制與程式燒錄等功能
|
|
|
UCD3138(64-pin)開放式系統 |
-
採用UCD3138(64-pin)數位處理器的開放式系統，包含基本周邊、腳位控制與程式燒錄等功能
|
 |
高壓Digital Resonant
LLC Converter開發平台(採用UCD3138處理晶片) |
- Digitally controlled LLC resonant
half-bridge DC-DC power conversion DC line input from 350 to
400Vdc
- Regulated output 12Vdc with output from
no-load to full-load
- Full-load power 340W, or full-load
current 29A
- Synchronous rectification
- Constant Current/Constant Power control
mode
|
 |
Hard Switching Full
Bridge全橋轉換DC/DC開發平台(採用UCD3138處理晶片 |
- Digitally controlled and standalone hard
switching full-bridge DC-DC power conversion Voltage mode control
- Secondary side control
- DC input from 36
to 72Vdc
- 12Vdc regulated output from no-load to
full-load
- Full-load power 360W, or full-load
current 30A
- Constant soft start time
- Protection: over voltage, under voltage,
over current, and over temperature
|
 |
高壓相位移位全橋DC/DC開發平台(採用UCD3138處理晶片 |
- Digitally controlled phase-shifted
full-bridge DC-DC power conversion
- DC line input from 350 to 400Vdc
- Regulated output 12Vdc with output from
no-load to full-load
- Full-load power 360W, or full-load
current 30A
|
 |
高壓Digital
Power Factor Correction Pre-regulator開發平台(採用UCD3138處理晶片 |
- Universal AC Line Input from 90 VAC to
264 VAC with AC Line Frequency 47 Hz to 63 Hz
- Regulated Output 390 VDC with Output from
No-Load to Full-Load
- Full-Load Power 360 W, or full-Load
Current 0.92 A
- High Power Factor and extremely Low THD
even at light load (below 5% in most operation conditions)
|
 |
UCD3138 &
UCD3138064控制卡 |
|
 |
USB adapter |
- 採用PMBus溝通介面的程式燒錄器，可進程式燒錄、抹除與記憶體和checksum檢查
|
 |
XDS1xx
V3模擬器 |
-
第三代XDS1xx
USB介面模擬器，可支援UCD3138在CCS6.x之下，進行程式編譯與執行
|
|
|
Code Composer Studio V12.x
New! |
-
最新版軟體開發環境，可支援全系列MSP430/ARM/DSP處理器，可安裝於WIN7/8/10
|
